Electric Outboard RIM Drive 2.5 – Entry Level – Tiller
A reliable electric outboard with tiller and display built for control, efficiency and silence. It is the result of many years of experience with non-tiller outboards. This new version adds a strong tiller and a clear display that shows essential motor information and, if desired, battery status. This 2.5kw motor is engineered to perform in the toughest conditions and offers complete confidence on the water. The tiller makes steering smooth and precise, while the display keeps you fully informed at every stage of your journey.
Specifications – Electric Outboard RIM Drive 2.5 – Entry Level – Tiller
- Nominal current: 120A
- Nominal voltage: 24V
- Weight: 20kg
- Propeller diameter: 86mm
- Outside diameter: 141mm
- Motor length: 149mm
- Total length: 912mm
- Static thrust: 24kg
- Motor controller included: Yes
The Outboard can be used in a salt water environment. All materials are carefully selected to maintain optimal performance and endurance. However, this requires the use of an anode to protect the motor. For additional instructions please see the manual of the motor.
Technically the motor could be used with any battery as long as this can provide the necessary power. However, we are able to offer one of the lowest prices per Watt-hour available. Solid State or Lithium batteries offer more performance per unit of weight then lead-acid batteries. In case you are not convinced by RDT batteries, we still advise to contact us point to make sure the correct batteries are selected.
Entry Level Outboard
| Model | Entry Level Outboard |
| Type | 2.5 |
| Input voltage | 24 |
| Nominal power | 2.5 |
| Maximum RPM | 3.200 |
| Maximum temp. | 85°C |
| Temp. sensor | PT1000 |
| Maximum depth* | 5 meters |
Motor controller
| Motor controller | 48V 250A |
| Length mc | 160 mm |
| Width mc | 200 mm |
| Height mc | 72 mm |
| Weight mc | 3.25 kg |
The Rim Drive Technology 2.5 kW Entry Level Tiller is a 24V, 20 kg hubless electric outboard producing 24 kg of static thrust. Its open, axle-less propeller design prevents weeds and ropes from tangling, making it ideal for shallow or heavily vegetated waters with an IP68 saltwater-resistant build.
