New Torqeedo Ultralight 1103 AC 3 HP Electric Outboard
Description
Weight: 15.3 kg complete with battery
3 HP equivalent
With 915 Wh high-performance lithium battery
Comes including charger, throttle, onboard computer, GPS-based range calculation and emergency magnetic kill switch
New angler mount with tilt and park mechanism, plus simple integration with the kayak’s steering unit
Easy to mount on fishing kayaks
Range of up to 50 km
Ultralight 1103 AC
Ultra-powerful. Ultra-efficient. Ultra-stealthy. The Ultralight 1103 AC Professional kayak anglers don’t hit the water without their Ultralight, and neither should you. With the Ultralight 1103 AC, you can now beat the crowd and get to that coveted spot up to 30% faster. The whisper-quiet, direct-drive Ultralight 1103 AC comes with the innovative angler mount and all the hightech features you’ve come to expect: GPS built-in, realtime range and runtime display, solar charging, superior safety and performance, and the latest lithium battery technology. The 1103 AC is almost three times more powerful than the Ultralight 403 for the ultimate in acceleration and pulling power, and adds instant throttle response for improved manoeuvrability and a heavy-duty construction with more resistance to impact damage.
Our extremely light Ultralight 1103 AC fits on all popular types of kayak and canoes, and there are special models for special requirements.
Ultralight 1103 AC – Benefits:
Weight including battery: 15.3 kg
Range of up to 50 km
Easy to mount on fishing kayaks
Completely waterproof (IP67)
Superb usability with a wealth of smart features
Ultralight 1103 AC with Integrated Battery (915 WH / 29.6 V / 31 Ah)
Speed in km/h* Range in km* Running time in hours
Slow 5.8 53.3 09:11
Half throttle 10.9 15.9 01:28
Full throttle 12.5 10.4 00:48
Technical Data Ultralight1103 AC
Input power in watts 1100
Propulsive power in watts 540
Comparable petrol outboards (propulsive power) 3 HP
Comparable petrol outboards (thrust)
Maximum overall efficiency in % 49
Static thrust in lbs*
Integrated battery 915 Wh Li-Ion
Nominal voltage 29.6
Final charging voltage 33.6
Total weight in kg 15.3
Motor weight without battery in kg 9.3
Weight of integrated battery 6.0
Shaft length in cm 51
Standard propeller
(v = speed in km/h at p = power in watts) v10/p1100 weedless
Alternative propeller options –
Propeller Guide
Maximum propeller speed in rpm 1,450
Control Throttle
TorqLink No
Steering Connects to kayak steering, lockable
Tilting device Manual, with impact protection
Trim device Manual, 4-step
Stepless forward/reverse drive Yes
Integrated on-board computer Yes
Technical information : New Torqeedo Ultralight 1103 AC 3 HP Electric Outboard
Power Supply EDAC EA11012E-240
Input Voltage 100 – 240 VAC
Input Frequency 50 – 60 Hz
Output Voltage 24 VDC
Output Current 4.16 A
Output Power 100 W
Average operational efficiency ≥ 89 % at 25 %, 50 %, 75 %, 100 % output power
Efficiency at light loads (10 %) ≥ 79 %
No Load Power consumption ≤ 0,15 Wat at 0 % output power
