New Yanmar 1GM10 9HP Inboard Diesel Engine

New Yanmar 1GM10 9HP Inboard Diesel Engine

Brand new GM Series 1GM10 9HP/7kW complete With Flexible Mounts, Control Panel, Tacho Kit, Wiring Loom, Your Choice Of Output Gearbox With Full Yanmar Warranty.

Famed for their reliability, the GM Series diesel single cylinder feature pre-combustion chamber indirect injection. Yanmar marine leisure diesel gives you the easiest start, provides more power and produces outstanding torque at low engine speeds. It is even quieter with smoke virtually eliminated. Clean running, smooth and with its outstanding size and power-to-weight benefits.

Specifications

Rated Output
6.6 kW / 9 mhp

Rated Speed
3600 rpm

Displacement
0.318 L / 19.41 cu. in

No. of cylinders
1 cylinder

Cylinder Bore x Stroke
75 mm x 72 mm / 2.95 in x 2.83 in

Combustion system
Indirect Injection, In-line Pump

Aspiration
Natural

Alternator
12V – 40A

Dry weight without gear
71 kg / 156.5 lbs

Dimensions
554 mm x 410 mm x 485 mm

Controls
Mechanical

Certifications
RCD 2 EPA Tier 2 BSO II EMC

NOTE : New Yanmar 1GM10 9HP Inboard Diesel Engine

1 kW = 1.3596 mhp = 1.34102 bhp
Fuel condition: density at 15°C = 0.842 g/cm³
Technical data is according to (ISO 8665) / (ISO 3046)
Fuel temperature 40°C at the inlet of the fuel injection pump (ISO 8665)
Length includes KM2P-1 marine gear
(Dimensions may vary with other gears/elbow)

Standard Engine Package

Exhaust mixing elbow [L-type]
Alternator 12V – 40A
A panel
Flexible mounts

Optional Accessories

B20 panel
Extension wire harness [3m]
TFX Sidemount control head
Propeller cone nut kit SD25
On-board spare parts kit

The Yanmar 1GM10 9HP inboard diesel engine is a very popular, reliable and compact raw-water cooled single-cylinder engine for small sailboats (sailboat auxiliary propulsion) as well as light recreational boats. This engine is renowned for its optimal power-to-weight ratio, saving space in the ship’s hold.

Here are the key technical specifications and standard equipment typically offered for new units:

Main Technical Specifications

Engine Model: 1GM10

Engine Type: Vertical, 1-cylinder, 4-stroke, diesel engine

Maximum Power Output: 9 HP (6.62 kW) at 3600 RPM

Combustion System: Special swirl pre-combustion chamber

Cooling System: Direct seawater cooling / raw-water cooling

Cylinder Capacity: 0.318 Liters (318 cc)

Starting System: Electric (with manual combination crank option)

Alternator Output: 12V – 35A

Engine Dry Weight: Approximately 72 kg (without oil and water)

Fuel Consumption: Very efficient, approximately 1.0 Liters/hour at cruising speed
