Electric Steerable POD Motor RIM Drive 3.0
The Steerable POD, a pinnacle of innovation with a maximum input power of 3.0kW and a 48V nominal voltage, ensuring optimal efficiency surpassing 90%. Experience unparalleled acceleration compared to conventional alternatives, coupled with zero-turn steering. The steerable POD is rotatable up to 320 degrees with 160 degrees both ways for ultimate manoeuvrability. All combined in a lightweight compact design.
Enjoy diverse control options with joystick, steering wheel, or CAN control. Adding to its resilience, all our POD motors are fully waterproof with an IP68 rating, achieved by completely casting the motor not by using sealings. The design also minimizes risk of damage to the propeller, perfect performance in any environment
Mounting plates and sealing for our steerable POD motor are available in stainless steel (RVS) and fiberglass (GFK). In addition, an ECU is available. All drawings can be downloaded below in the ‘Downloads’ section.
Specifications – Electric Steerable POD Motor RIM Drive 3.0
- Nominal current: 63A
- Nominal voltage: 48V
- Weight: 21.5kg
- Propeller diameter: 86mm
- Outside diameter: 135mm
- Motor length: 150mm
- IP Class: IP68
- Static thrust: 31kg
- Salt water resistant: Yes
- Motor controller included: Yes
Steerable POD
| Model | Steerable POD |
| Type | 3.0 |
| Input voltage | 48 |
| Nominal power | 3.0 |
| Maximum RPM | 4.000 |
| Maximum temp. | 85°C |
| Temp. sensor | PT1000 |
| Maximum depth* | 5 meters |
Motor controller
| Motor controller | 48V 250A |
| Length mc | 160 mm |
| Width mc | 200 mm |
| Height mc | 72 mm |
| Weight mc | 3.25 kg |
Key Technical Specifications
Maximum Input Power: 3.0 kW
Nominal Voltage: 48 V (Nominal current: 63 A)
Static Thrust: 31 kgf
Steering System: Rotatable up to 320 degrees (+/- 160 degrees to each side) for zero-turn capability.
Motor Dimensions: Length 150 mm, Outer Diameter 135 mm, Propeller Diameter 86 mm.
Total Weight: 21.5 kg (or 15.5 kg for the Entry-Level variant).
Protection Class: IP68 (Fully waterproof thanks to a complete casting method, rather than just rubber seals).
Key Advantages
Rim Drive 3.0 Technology / Hubless Design: Features only one rotating part. With no gears or drive shafts, the risk of ropes or debris tangling and damaging the motor is minimal.
Instant Acceleration: Capable of accelerating from a standstill (0 RPM) to full RPM in just 1.5 seconds.
High Efficiency: Boasts an energy efficiency rate exceeding 90%.
Flexible Control: Compatible with various control options, ranging from joysticks and conventional steering wheels to digital CAN-bus integration.
Eco-friendly & Quiet: Operates almost silently and is emission-free, making it ideal for sensitive waters or conservation lakes.
