Name: Electric Outboard RIM Drive 5.0 - Entry Level - Tiller
SKU: 6850
Availability: InStock

Electric Outboard RIM Drive 5.0 – Entry Level – Tiller

A reliable electric outboard with tiller and display built for control, efficiency and silence. It is the result of many years of experience with non-tiller outboards. This new version adds a strong tiller and a clear display that shows essential motor information and, if desired, battery status. This 5.0kw motor is engineered to perform in the toughest conditions and offers complete confidence on the water. The tiller makes steering smooth and precise, while the display keeps you fully informed at every stage of your journey.

Specifications – Electric Outboard RIM Drive 5.0 – Entry Level – Tiller

Nominal current: 104A
Nominal voltage: 48V
Weight: 23kg
Propeller diameter: 133mm
Outside diameter: 191mm
Motor length: 149mm
Total length: 967mm
Static thrust: 60kg
Motor controller included: Yes

The Outboard can be used in a salt water environment. All materials are carefully selected to maintain optimal performance and endurance. However, this requires the use of an anode to protect the motor. For additional instructions please see the manual of the motor.

Technically the motor could be used with any battery as long as this can provide the necessary power. However, we are able to offer one of the lowest prices per Watt-hour available. Solid State or Lithium batteries offer more performance per unit of weight then lead-acid batteries. In case you are not convinced by RDT batteries, we still advise to contact us point to make sure the correct batteries are selected.

Entry Level Outboard

Model	Entry Level Outboard
Type	5.0
Input voltage	48
Nominal power	5.0
Maximum RPM	2.500
Maximum temp.	85°C
Temp. sensor	PT1000
Maximum depth*	5 meters

Motor controller

Motor controller	48V 250A
Length mc	160 mm
Width mc	200 mm
Height mc	72 mm
Weight mc	3.25 kg

The Electric Outboard RIM Drive 5.0 Entry Level with tiller is an axle-less, 48V electric motor producing 5kW of nominal power and 62 kg of static thrust. Designed by Rim Drive Technology, it features an IP68 waterproof build, zero oil/wear parts, and salt water resistance.

Technical Specifications

Nominal Voltage: 48V

Nominal Current: 104A

Static Thrust: 62 kg (approx. 62 kgf)

Propeller Diameter: 133 mm

Motor Length: 150 mm

Waterproof Rating: IP68 (fully submersible)

Weight: Approx. 17 kg to 23 kg depending on bracket/tiller config
