Yamaha F100 FETL 100HP 4 Stroke Long Shaft Outboard Engine
The latest F100 is now even lighter – so for genuine all-round performance, smooth acceleration and economy, it would be hard to beat. Yamaha’s innovative engineering makes it ultra-reliable too.
Our latest 4-stroke technology offers unmatched performance – thanks to a 16-valve engine with Single Overhead Camshaft (SOHC) for vivid acceleration, advanced intake and exhaust system designs – and Yamaha’s unique multi-point EFI (Electronic Fuel Injection)
A range of convenient features – including PrimeStart™, a high-output alternator, and Yamaha’s Wide-Range Power Trim & Tilt system – gives you the confidence that you’re in full control when you’re out there on the water.
Yamaha F100 FETL 100HP 4 Stroke Long Shaft Outboard Engine
Key Features
Powerful Acceleration & Lightweight Design: Compared to the previous generation, the latest SOHC structural engineering makes the engine significantly lighter without compromising torque performance.
PrimeStart™ System: Ensures easy and smooth engine starts in a single start without the need to manually pull the choke.
Digital Network Compatibility: Supports integration with Yamaha Digital Network Gauges to monitor crucial data such as RPM, operating hours, trim angle, and fuel consumption.
Easy Maintenance: The engine has a 3.2-liter oil capacity (with filter) and uses SAE 10W30 or 10W40 marine oil.
Yamaha F100 FETL Engine
Engine type: 4-stroke
Displacement: 1832 cm³
No. of cylinders/configuration: 4/In-line, 16-valve, SOHC
Bore x stroke: 81.0 mm x 88.9 mm
Prop shaft output at mid range: 73.6kW / 5,500 rpm
Full throttle operating range: 5,000 – 6,000 rpm
Lubrication system: Wet sump
Fuel Induction System: EFI
Ignition / advance system: TCI
Starter system: Electric
Gear ratio: 2.15 (28/13)
Yamaha F100 FETL Dimensions
Recommended boat transom height: L: 516mm
Weight with propeller: F100FETL: 162 kg
Fuel tank capacity: N/A
Oil pan capacity: 3.2 litres
Yamaha F100 FETL Additional features
Control: Remote control
Trim & tilt method: Power trim & tilt
Lighting Coil / Alternator: 12V – 35A with rectifier/regulator
Tilt limitter: Optional
Engine immobiliser: YCOP Optional
Propeller: Optional
Counter Rotation Model: N/A
Shallow Water Drive: Standard
Digital Network Gauge II (LCD Color): N/A
Digital Network Gauge (Round/Square): Optional
Variable Trolling RPM: With DN Gauges or m-f tiller handle
Dual Battery Charging System: N/A
Shift Dampener System (SDS): Optional
