Raymarine Cyclone Pedestal – 55w

Cyclone Pedestal – 55W

Raymarine’s Cyclone Radar Pedestal 55 Watts. The base Cyclone models deliver 55-watt output power/6kW equivalent magnetron performance. All Cyclone models integrate seamlessly with Raymarine Axiom, Axiom+, Axiom Pro, and Axiom XL multifunction displays.

All Axiom displays require the forthcoming LightHouse Hvar 3.16 software update for complete Cyclone compatibility.

Raymarine Cyclone Pedestal – 55w

• Max Range Scale: 72 nautical miles.
• Pedestal Weight: 16Kg
• Waterproof Rating: IPX6
• Maximum Wind Speed: 100 Knots
• Power Consumption (Max): 170W
• Standby Power: 30W

Solid State Open Array Marine Radar

The ultimate expression of design rugged performance and unmatched situational awareness Cyclone solid-state open array radars give mariners the confidence to tackle the harshest conditions gain the upper hand in the hunt for fish and navigate busy waterways with confidence.

Cyclone radars deliver superior target separation and long-range resolution using CHIRP pulse compression and Raymarine beam sharpening technology. Each model features innovative detection capabilities including Cyclone Bird Mode RangeFusion technology and high speed 60 rpm imaging.

Cutting Edge Design

Aircraft Wing Inspired: Engineered for extremes with best-in-class 100-knot wind rating and designed to meet the commercial grade IEC 62388 standard for ship bourne radar.

Low Profile: At 13.1 inches (335 mm) tall Cyclone’s lower profile allows greater flexibility of boat architecture and more adaptable installation options.

Clean Installation: Innovative pedestal design conceals cable connections for a cleaner installation. Built in cable gland to allow sleeker design configuration to boat designers.

The Ultimate Situational Awareness

360 Degrees of Awareness: Fast 60 RPM rotational speed delivers 360 degrees of awareness and accurate target tracks in real-time.

Doppler Target Tracking: Doppler target tracking simplifies the interpretation of dangerous and safe targets for added safety.

Professional Grade ARPA: Professional grade ARPA target tracking. Cyclone automatically tracks up to 50 targets using the same advanced ARPA technology trusted by the United States Coast Guard.

Range Fusion: RangeFusion technology combines short and long pulses into the single high clarity radar image delivering exceptional short-range and long-range targets simultaneously.

Cyclone Birdmode Fishing Intelligence: Performance tuned for locating sea birds. Enhanced Cyclone Bird Mode uses CHIRP pulse compression technology to allow Cyclone to intelligently optimize gain and tune settings for imaging distant sea birds.
