Name: New Yamaha F75 75HP 4 Stroke Long Shaft Outboard Engine
SKU: 6039
Availability: InStock

New Yamaha F75 75HP 4 Stroke Long Shaft Outboard Engine

In stock

With its advanced 16-valve, four-valve-per cylinder, Single Overhead Camshaft (SOHC) design and large 1.8 Litre displacement, the F75 delivers the ultimate combination of unbridled power and refined performance for the mid-range outboard market. The F75’s lightweight powerhead configuration, refined shaping of the combustion chamber and lean fuel burn technology, means this outboard is extremely fuel efficient, while also delivering an exceptionally smooth and quiet riding experience. This outboard is compatible with Yamaha’s comprehensive range of Command Link gauges and NMEA2000 compliant, meaning you can share engine information with third party multi-function displays, GPS and fish finder systems.

Buy it now

New Yamaha F75 75HP 4 Stroke Long Shaft Outboard Engine

FEATURES :

Updated look: The compact new F75 adopts an updated cowling to keep it consistent with the look of the Yamaha outboard lineup.
Multi-point fuel injection: With Multi-point Fuel Injection, Fuel is delivered at the optimum volume and time according to ECU sensor signals. This ensures quick starts, efficient fuel consumption, and ample power along with ultra-low emissions.
Command link compatibility: The F75 is compatible with Yamaha’s Command Link 6Y8 and 6YC digital gauges, as well as Y-COP.

SPECS : New Yamaha F75 75HP 4 Stroke Long Shaft Outboard Engine

ENGINE

ENGINE TYPE 4-cylinder
DISPLACEMENT 1596cc (97ci)
BORE & STROKE 79×81.4mm (3.11×3.2in)
RPM RANGE 5000-6000
COMPRESSION RATIO 9.6:1
INDUCTION SYSTEM DOHC
ALTERNATOR OUTPUT 20 Amps
FUEL DELIVERY EFI
STARTING Electric
IGNITION TCI microcomputer
LUBRICATION Wet sump
DEGREE OF TRIM/TILT -4° through 16°/70°
EXHAUST Through Prop
COOLING Water/Thermostatic Control
GEAR SHIFT F/N/R
GEAR RATIO 11:25 (2.27)

The Yamaha F75 75HP 4 Stroke Long Shaft (F75LB) outboard engine is one of the best mid-range engine choices that offers a balance between high power, high fuel efficiency, and light weight. Using the same 1.8 Liter inline 4-cylinder engine base as the F90 model, this engine is specifically designed to provide abundant torque at medium revs while still having a compact dimension.

Key Specifications (Model F75LB)

Based on official technical data from Yamaha Motor, here are the detailed specifications of this engine:

Engine Type: 4-Stroke, 16-Valve SOHC In-line 4-Cylinder

Cylinder Capacity: 1832 cc

Shaft Length: Long Shaft (L) – 516 mm / 20.3 inches

Fuel System: Electronic Fuel Injection (EFI)

Dry Weight: 162 kg

Maximum RPM Range: 5000 – 6000 RPM

Alternator Output: 12V – 35 Ampere with rectifier regulator

Trim & Tilt System: Power Trim & Tilt Control System:

Mechanical (supports optional tiller handle)

FUEL & LUBRICATION

RECOMMENDED FUEL Regular Unleaded (Minimum Pump Octane 87)
RECOMMENDED OIL Yamalube 4-M FC-W 10W-30 or 20W-40
OIL CAPACITY 4.5L (4.8 qt)

DIMENSIONS

SHAFT LENGTH 20″
DRY WEIGHT 168kg (369 lb)
