Name: New Yamaha F60 60HP 4 Stroke Long Shaft Outboard Engine
SKU: 6047
Availability: InStock

New Yamaha F60 60HP 4 Stroke Long Shaft Outboard Engine

MIDRANGE 60 hp

Our 1-liter 60-hp midrange offers light weight and exhilarating performance. A dynamite choice for the inshore angler, it gives you the option of dialing in trolling speeds in precise, 50-RPM increments. Depending on your gauge and control preference, the F60 allows you to access to our Variable Trolling RPM Switch (VTS®) via our Multi-Function Tiller Handle, Command Link® Tachometer or a helm-mounted remote VTS switch.

Available for mechanical remote or tiller control
Only 247 pounds
Available in a 20” shaft
Powerful 16-amp alternator
Optional Variable Trolling RPM Switch (VTS®)
Available in a T60 High-Thrust model for heavy loads and an F60 Jet-Pump model for shallow water (F60 Jet model produces 40 horsepower at the jet pump nozzle)

SPECS : New Yamaha F60 60HP 4 Stroke Long Shaft Outboard Engine

ENGINE TYPE 4-cylinder
DISPLACEMENT 996cc (60.8ci)
BORE & STROKE 65x75mm (2.56×2.95in)
RPM RANGE 5000-6000
COMPRESSION RATIO 9.5:1
INDUCTION SYSTEM SOHC
ALTERNATOR OUTPUT 17 Amps
FUEL DELIVERY EFI
STARTING Electric
IGNITION TCI microcomputer
LUBRICATION Wet sump
DEGREE OF TRIM/TILT -4° through 20°/69°
EXHAUST Through Prop
COOLING Water/Thermostatic Control
GEAR SHIFT F/N/R
GEAR RATIO 13.24 (1.85)

The Yamaha F60 is a silky-smooth, 996cc, 4-cylinder, 4-stroke long-shaft outboard engine. Weighing approximately 113 to 117 kg (247-262 lbs), it delivers an excellent power-to-weight ratio and outstanding fuel economy.

Key Specifications

Engine Type: Inline 4-cylinder, single-overhead camshaft (SOHC)
Displacement: 996 cc
Shaft Length: 20-inch (Long Shaft – Model F60LB)
Dry Weight: Approx. 117 kg (247-262 lbs depending on rigging)
Fuel System: Electronic Fuel Injection (EFI) for clean, efficient, and reliable performance
Starting System: PrimeStart for effortless, car-like ignition
Alternator Output: 16-amp (keeps onboard electronics charged)
Trim & Tilt: Wide Range Power Trim and Tilt

Standout Features

Compact & Lightweight: Its 1-liter block is surprisingly compact, making it a dynamite match for skiffs, pontoons, and inshore fishing boats.
Low Noise & Vibration: The 4-cylinder long-stroke design minimizes noise and vibration for a more comfortable day on the water.
Trolling Advantage: Features Variable Trolling RPM (via Yamaha’s Command Link system) allowing anglers to adjust trolling speeds in precise 50 RPM increments

FUEL & LUBRICATION

RECOMMENDED FUEL Regular Unleaded (Minimum Pump Octane 87)
RECOMMENDED OIL Yamalube 4-M FC-W 10W-30 or 20W-40
OIL CAPACITY 2L (2.1 qt)

DIMENSIONS

SHAFT LENGTH 20″
DRY WEIGHT 112kg (247 lbs)
