New Torqeedo Cruise 4.0T Electric Outboard Motor
DESCRIPTION
The lightest, most powerful and most efficient electric outboards available, the Torqeedo Cruise 4.0 is the leading electric solution for pontoon boats, sailboats, small boats, commercial operations and users on lakes that limit the use of combustion motors.
The Cruise 4.0 is comparable to an 8 HP petrol outboard and can be easily mounted on your boat with a couple of tools, regardless of whether the remote or tiller version.
A power supply from at least two lithium batteries (Power 24-3500) or with lead batteries (lead-gel or AGM) must be provided for operation.A power supply from at least two lithium batteries (Power 24-3500) or with lead batteries (lead-gel or AGM) must be provided for operation.
Benefits:
High-efficiency outboard with 4,000 W input power, equivalent to an 8 HP petrol outboard.
We recommend the Cruise 4.0 for dinghies and sailboats up to to 4 tons.
This model is equipped with tiller control.
Rugged aluminium pylon with reinforced fin – extra robust even when running aground.
Shaft sealant rings mounted in protected area on the inside of the pylons
Highest-grade seawater-proof aluminium (AlMgSi1), hard-anodized for long service life, even in the harshest conditions
Lubricant-free polymer plain bearings protect against damage from fishing lines or debris and provide improved mechanical support for propeller shaft – wear-resistant and maintenance-free.
Comprehensive galvanic corrosion protection through careful matching of all materials and meticulous isolation of materials with different electrochemical properties.
Aluminium fin coated in polyurethane foam provides additional protection from impact when running aground.
Everything is waterproof to IP67.
SPECS : New Torqeedo Cruise 4.0T Electric Outboard Motor
Input power in watts 4000
Propulsive power in watts 2240
Comparable petrol outboards (propulsive power) 8 HP
Comparable petrol outboards (thrust) 9.9 HP
Maximum overall efficiency in % 56
Static thrust in lbs* 189
Integrated battery –
Nominal voltage 48
Final charging voltage –
Total weight in kg 18.3 (S) / 19.4 (L)
Motor weight without battery in kg –
Weight of integrated battery –
Shaft length in cm 62.5 (S) / 75.5 (L)
Standard propeller
v = speed in km/h at p = power in watts v20/p4000
Alternative propeller options v30/p4000, v8/p350
Propeller Guide
Maximum propeller speed in rpm 1300
Control Tiller
Steering 360° lockable
Tilting device Manual with grounding protection
Tilt angle 61,3°
Trim device Manual, 4-step
Integrated on-board computer Yes
Stepless forward/reverse drive Yes
