Mercury 25HP EFI 25ELHPT Outboard Motor
Product Description
Features
- Utilizes a three-cylinder engine design, delivering superior balance performance over twin-cylinder designs
- Compact and powerful
- Offers extra displacement and great low-end torque, putting the boat smartly on plane
- High output 15amp alternator for constant battery charging
- Battery-free electronic fuel injection delivers easy-starting, crisp throttle response and increased fuel economy
- Engine protection operator warning system including: low oil pressure, over-rev, overheat and sensor failure
- Mercury 3 year warranty
- PROPELLER NOT INCLUDED
- TRANSOM/CLAMP SCREWS NOT INCLUDED
Specifications :
| MODEL | 1A25411BK |
|---|---|
| MODEL YEAR | 2025 |
| SKU | 25ELHPT-25EFI |
| WEIGHT | 177.0 lb |
| MANUFACTURER | Mercury |
| COUNTRY OF MANUFACTURE | Japan |
| HORSEPOWER | 25hp |
| SHAFT LENGTH | 20″ (Long) |
| STEERING | Tiller |
| STARTING | Electric |
| TRIM & TILT | Power Trim & Tilt |
| FUEL DELIVERY | EFI |
| FUEL TANK | External |
| CYLINDER(S) | 3 |
| DISPLACEMENT | 526 Cubic Centimeter |
| BORE AND STROKE | 2.40 x 2.36 in. (61 x 60 mm) |
| FULL THROTTLE RPM RANGE | 5,000 – 6,000 |
| IGNITION SYSTEM | CDI with electronic spark advance |
| INDUCTION SCAVENGING | SOHC |
| VALVES PER CYLINDER | 2 |
| FUEL TYPE | 87 Octane (up to 10% ethanol content) |
| OIL TYPE | Mercury 4-Stroke Outboard Oil |
| ALTERNATOR | 15A, 186W |
| COOLING SYSTEM | Water-cooled with thermostat |
| SALTWATER RATED | Yes |
| GEAR RATIO | 1.92:1 |
| GEAR SHIFT | F-N-R Gearcase options – Standard |
| PROPELLER | No |
| INTERNAL BATTERY | No |
In the Box : Mercury 25HP EFI 25ELHPT Outboard Motor
- Fuel Tank (6.6 gallon)
- Quick Connect Fuel Line
- Mercury 3-Year Warranty
- Mercury 4-Stroke Oil
- Owner’s Manual & Tool Kit
- PROPELLER NOT INCLUDED
- TRANSOM/CLAMP SCREWS NOT INCLUDED
The Mercury 25HP EFI 25ELHPT Outboard Motor is a 4-stroke, 3-cylinder marine engine designed to deliver high fuel efficiency, low vibration, and reliable performance in small fishing boats, jon boats, and inflatable boats. The 25ELHPT model features a highly sought-after configuration: electric starter, tiller control (arm steering), long shaft (20 inches), and an automatic Power Trim & Tilt system.
Here are the unit code meanings, technical specifications, and featured features of this outboard engine.
Series Code Meaning (25ELHPT)
25: Engine horsepower (25 horsepower).
E: Electric Start (Electric starter system uses a battery).
L: Long Shaft (Engine leg shaft length 20 inches / 508 mm).
H: Hand/Tiller Steering (Directly controlled using a manual steering arm).
PT: Power Trim & Tilt (Automatic hydraulic system to adjust the engine’s tilt angle in the water).
