Maretron 8″ Vessel Monitoring & Control Touchscreen

The TSM810C is an 8″ dedicated touchscreen that includes Maretron’s N2KView® vessel monitoring and control software. The N2KView® software allows you to configure as many favorite screens as you want with exactly the information you want to see. The TSM810C provides an extremely simple touch interface for monitoring and controlling critical systems from anywhere on the vessel.

The TSM810C is ruggedized for marine use and includes a solid state disk drive to withstand the pounding associated with waves. And since the TSM810C only dissipates 10 watts, there is no need for internal cooling fans that are noisy and wear out causing electronics to overheat and fail. The TSM810C can be mounted outside given the high bright screen and waterproof front.

As an alternative to controlling the TSM810C through the touch screen, the TSM810C includes two USB ports for connecting keyboards, mice, or trackballs. The TSM810C also has an Ethernet port for connecting Internet Protocol (IP) cameras for viewing within the N2KView® software.

Lastly, the TSM810C contains two completely isolated CAN bus connectors (M12) for easy connection to single or redundant NMEA 2000® networks.

Features:

• 8” TFT LCD Panel, LED Backlit
• Widescreen Aspect Ratio 5:3
• 800 x 480 Pixels
• 1350 nits Brightness (Optically Bonded)
• Solid State Disk Drive
• Fanless Cooling System
• Flush or VESA Mounting
• Dual CAN Bus for Single or Redundant NMEA 2000® Network Connections

The Maretron 8″ Vessel Monitoring & Control Touchscreen generally refers to the Maretron TSM810C (latest generation) or its predecessor, the TSM800C. This device is a dedicated, integrated touchscreen designed to monitor and control all of your vessel’s critical systems in real time.

Key Features & Specifications Maretron 8″ Vessel Monitoring & Control Touchscreen

Pre-installed N2KView® Software: Comes with the full version of N2KView® software. You can freely configure the screen layout, analog charts, digital gauges, alarms, and even electrical switch controls to your liking.

Bright & Weatherproof (Daylight Readable): Utilizes an 8-inch TFT LCD panel with a resolution of 800 x 480 pixels. Thanks to optically bonded technology and a brightness of up to 1350 nits, the screen remains highly visible under direct sunlight and is safe for outdoor installation or on flybridges (IP66 front).

Ruggedized & Fanless Design: Fanless, devoid of internal fans, reduces noise and reduces the risk of overheating. fan failure. The internal components use a Solid State Drive (SSD) that is resistant to severe shocks and wave impacts.
