Honda 100HP | BF100A1XRT

Honda 100HP | BF100A1XRT

Motor Specifications

• Engine Type: Honda BF100A1XRT Four Stroke
• Horsepower: 100 hp
• Cylinders: 4 cyl
• Shaft Length: 25″
• Steering: Remote Mech
• Starter: Electric
• Weight: 365 lbs
• Full Throttle Range: 5300 – 6300 rpm
• Displacement: 1496cc
• Induction System: EFI (Recommended 91 Octane)
• Warranty: 5 years

*Prop not included.

Standard Features

Charging system, freshwater flush system, power trim & tilt, owner’s manual

The Honda BF100A1XRT is a powerful and lightweight 100 HP four-stroke outboard engine. Equipped with a 25-inch (X-long) shaft, mechanical remote throttle, and electric starter, this engine is designed to maximize performance and fuel efficiency.

Key Specifications – Honda 100HP | BF100A1XRT

Engine Power: 100 HP

Engine Type: 1.5L 4-cylinder SOHC (4 valves per cylinder)

Fuel System: Programmed Fuel Injection (PGM-FI)

Weight: 163 kg (one of the lightest in its class)

Shaft: 25 inches (X-long)

Steering & Throttle: Mechanical remote control with Power Tilt & Trim

Superior Technology Features

VTEC (Variable Valve Timing and Electronic Control): Delivers smooth power at low rpm and maximum performance at high rpm.

BLAST (Boosted Low Speed ​​Torque): Delivers exceptional torque at low revs for rapid acceleration.

ECOmo Lean Burn Control: Optimizes the air-fuel ratio, enabling up to 20% better fuel efficiency at cruising speeds.

3-Way Cooling System: Three separate cooling circuits (cylinder, cylinder head, manifold) to maintain optimal temperatures and maximum reliability.

The Honda BF100A1XRT outboard engine is a 100-horsepower, mid-range 4-stroke marine motor that combines superior fuel efficiency with reliable performance. This engine is specifically designed for medium-sized vessels such as bay boats, aluminum fishing boats, and pontoons.

The BF100A1XRT model code indicates the manufacturer’s specific specifications:

Uses a 25-inch extra-long shaft.

Uses a remote mechanical throttle and shift control.

Equipped with electric power trim and tilt adjustment.

Featured Features – Honda 100HP | BF100A1XRT

VTEC® Technology: Electronically controls valve timing and lift to deliver abundant power at high RPMs while maintaining a smooth ride at low RPMs.

BLAST™ (Boosted Low-Speed ​​Torque): Optimizes the air-fuel mixture and ignition timing during rapid acceleration to provide instant thrust from low speeds.

Lean Burn Control (ECOmo): Delivers best-in-class fuel efficiency. This system allows the engine to operate with a leaner fuel mixture at cruising speeds.

NMEA 2000 Connectivity: Enables direct engine data integration into your boat’s GPS or chartplotter display.

Best Charging: A 44-Amp alternator ensures faster battery charging to power various navigational electronics and additional fishing sonar.
