ePropulsion Electric Motor Battery G102-230
G-Series – Lithium Iron Phosphate Battery (LiFePO4) 23552 Wh / 96V LiFePO4 battery with 3500 cycles of battery life
New connector to ensure 360° rotation is possible.
High-performance and durable lithium battery for electric boating
- 1C Rate Fast Charging Certification
- Waterproof to IP67
- CE, UKCA, FCC, and UN38.3 Certification
Fully Compatible with ePropulsion Motors
Power the 96V 10kW to 40kW ePropulsion motors including the X/I/P Series motors.*
High Energy Density
3 times higher energy density and 70% less weight than lead acid batteries.**
Maximum Safety
The built-in intelligent battery management system (BMS) is applied to provide maximum safety for the users.
Easy to Install
Connectors can be installed with only ONE hand, and the battery saves wiring harness connection compared to series-parallel connection of battery.
Space Saving
The slim battery design optimizes under-boat or seat storage, ideal for space-saving on RIBs and pontoon boats.
Long Life Cycle
The G102-230 (3,500 cycles at 80% DOD) and G102-100 (3,000 cycles at 80% DOD) both last longer than lead-acid batteries.**
High Reliability – ePropulsion Electric Motor Battery G102-230
All-metal housing is more reliable, weather resistant, impact resistant and drop proof.
* G-Series batteries can be connected in parallel to power different ePropulsion motors.
** Under equal capacity.
| G102-100 | G102-230 | |
|---|---|---|
| Chemistry | Lithium Iron Phosphate (LiFePO4) | Lithium Iron Phosphate (LiFePO4) |
| Rated Voltage | 102.4 V | 102.4 V |
| Capacity | 10240 Wh / 100 Ah | 23552 Wh / 230 Ah |
| Battery Life | 3,000 cycles at 80% SoH | 3,500 cycles at 80% SoH |
| Weight | 100 kg (220.5 lbs) | 180 kg (396.8 lbs) |
| Dimensions | 680 x 500 x 300 mm (26.8 x 19.7 x 11.8 in) | 1287 x 366 x 295 mm (50.7 x 14.4 x 11.6 in) |
| Cut-off Voltage | 83.2 V | 83.2 V |
| Final Charging Voltage | 115.2 V | 115.2 V |
| Max Continuous Discharging Current | 100 A | 230 A |
| Serial Connection | N/A | N/A |
| Parallel Connection | Up to 8 in 1 cluster. Multiple clusters are possible in the system | Up to 8 in 1 cluster. Multiple clusters are possible in the system |
| Cell Configuration | 32S1P | 32S1P |
| Charging Temperature | 0°C to 55°C | 0°C to 55°C |
| Discharging Temperature | -10°C to 60°C | -10°C to 60°C |
| Communication | One CAN for ePropulsion motors / One CAN (Two ports) for parallel batteries / One CAN for charger | One CAN for ePropulsion motors / One CAN (Two ports) for parallel batteries / One CAN for charger |
| Shipping Classification | UN3480, Class 9, UN38.3 Certified | UN3480, Class 9, UN38.3 Certified |
| Approvals | CE, UKCA, FCC | CE, UKCA, FCC |
| Warranty (Non-Commercial Use) | 2 years | 2 years |
