Electric Outboard Battery ePropulsion E163
The ePropulsion E163 is a 48V, 163Ah Lithium Iron Phosphate (LiFePO4) battery designed for electric outboard motors. It delivers 8,345 Wh of capacity, weighs 76 kg (167 lbs), and offers up to 3,000 charging cycles. It features smart motor integration and an IP67 waterproof rating.
It provides extended range for higher-powered ePropulsion motors and features a robust metal casing.
Key Specifications
- Capacity: 163 Ah (8,345 Wh)
- Rated Voltage: 51.2 V
- Weight: 76 kg (167.5 lbs)
- Dimensions: 470 x 295 x 495 mm
- Cycle Life: 3,000 cycles to 80% depth of discharge
- Max Continuous Discharge Current: 150 A
Compatibility
The E163 is the officially recommended battery for the ePropulsion Navy 6.0 Evo outboard. It works with all ePropulsion 48V electric motors, which spans anything under 10hp (excluding the portable eLite series).
Features
- Battery Management System (BMS): Provides real-time monitoring and synchronizes directly with ePropulsion motors to prevent overheating, overcharging, and short-circuiting.
- Safety: LiFePO4 chemistry ensures a highly stable, non-hazardous battery that eliminates the risk of fire or overheating.
Electric Outboard Battery ePropulsion E163
|
E60
|
E163 | |
|
Capacity
|
3072 Wh / 60 Ah
|
8345 Wh / 163 Ah
|
|
Rated Voltage
|
51.2 V
|
51.2 V
|
|
Battery Life
|
3,000 cycles at 80% DOD
|
3,000 cycles at 80% DOD
|
|
Weight
|
33 kg
|
76 kg
|
|
Dimensions
|
512 x 290 x 300 mm
(20.2 x 11.4 x 11.8 in)
|
470 x 295 x 495 mm
(18.5 x 11.6 x 19.5 in)
|
|
Cut-off Voltage
|
41.6 V
|
41.6 V
|
|
Final Charging Voltage
|
57.6 V
|
57.6 V
|
|
Max Continuous Discharging Current
|
70 A
|
150 A
|
|
Serial Connection
|
N/A
|
N/A
|
|
Parallel Connection
|
Up to 16
|
Up to 16
|
|
Cell Configuration
|
16S4P
|
16S1P
|
| Charger | E-Series battery charger | E-Series battery charger |
| Charging Time (220V) | One charger: 2.7 Hrs Two chargers in parallel: 1.3 Hrs |
One charger: 7.2 Hrs Two chargers in parallel: 3.6 Hrs |
| Charging Time (110V) | One charger: 4 Hrs Two chargers in parallel: 2 Hrs |
One charger: 11 Hrs Two chargers in parallel: 5.4 Hrs |
| Charging Temperature | 0 to 55℃ (32 to 131˚F) | 0 to 55℃ (32 to 131˚F) |
| Discharging Temperature | -10 to 60℃ (14 to 140˚F) | -10 to 60℃ (14 to 140˚F) |
| Communication | Available: CAN-Bus for Parallel RS485 for ePropulsion motors |
Available: CAN-Bus for Parallel RS485 for ePropulsion motors |
| Shipping Classification | UN3480, Class 9, UN38.3 Certified | UN3480, Class 9, UN38.3 Certified |
| Approvals | CE, UKCA, FCC | CE, UKCA, FCC |
| Warranty (Non-Commercial Use) | 2 years | 2 years |
