Electric Outboard Aquamot 20kW Professional
Electric outboard motor from Aquamot with a power of 20 kW is suitable for boats up to approximately 10 tons displacement. The powerful electric motor from Aquamot is completely silent and 100% emission-free.
Safety with the Aquamot 20E
- Aquamot already has many years of experience and a wide dealer network in Germany, Austria, and Switzerland.
- Very robust. The Trend series from Aquamot consists of a lightweight aluminum housing.
- Durably usable in salt and fresh water thanks to seawater-resistant aluminum alloy.
- Attachment is done via 2 solid threaded studs.
- Clean solution: no risk of leaking fluids like oil.
- The engines come with a 2-year manufacturer warranty.
Comfortable Aquamot Outboard Motor
- The drive lever and controller are also made of high-quality aluminium.
- Maximum smoothness thanks to slow-turning, gearless electric motors.
- A colour display for the on-board computer is available as an option.
- Plug & Play connectors with intelligent circuitry in a high quality aluminium housing.
- Height-adjustable shaft for optimum immersion depth.
- The display shows the battery status and information about the motor.
Specifications : Electric Outboard Aquamot 20kW Professional
| Input Power | 21.69 kW |
| Output Power | 20 kW |
| Voltage | 96 V |
| Rotations Per Minute | 1500 rpm |
| Weight | 58 kg |
| Current | 225 A |
| Shaft length | 57 cm |
| Propeller | Bronze |
| Noise Level | Almost silent |
| Display | Battery monitor, board computer with optional color display |
| Control | Remote steering |
| Speed Control | Stepless |
| Saltwater Resistant | Yes |
| Tilting mechanism | Manual |
| Trimming mechanism | Manual |
The Aquamot 20kW Professional electric outboard (Model A200e) is a high-power, commercial-grade propulsion system designed for heavy-duty marine use on boats and displacements up to approximately 10 tons, featuring a brushless three-phase asynchronous motor, seawater-resistant aluminum housing, and extensive electronic safety protections.
Key Technical Specifications
- Power Output: 20 kW
- Design/Line: Professional Line (built for frequent commercial applications)
- Motor Type: 100% maintenance-free, brushless three-phase asynchronous motor
- Compatibility: Works with mono-cable, hydraulic, and cable-circulation steering systems
- Trim Positions: 4-position manual trim adjustment for ideal water positioning
Core Features & Protections
- Housing: Flow-optimized, seawater-resistant aluminum alloy housing to reduce drag and resist corrosion.
- Safety System: Electronic safeguards against overcurrent, deep discharge, overvoltage, undervoltage, runaway, and reverse polarity, plus a mechanical breaking point for grounding protection.
- Note on Purchase: Propellers for the Professional series are typically sold separately from the base motor unit.
