Electric Inboard Elco EP-12hp
The Elco Electric Propulsion System is well engineered using advanced technologies for reliable and outstanding performance. All of Elco’s products are built in the USA.
Elco Electric Motor: Cool, Quiet & Powerful
The entire propulsion system, excluding instrument panel and batteries, is contained in a water resistant cast aluminum finned housing that contains all of the electronics, PMAC motor, and safety devices. The system is mounted directly in place of a typical marine diesel or gas engine. Whether on the sound, around the bay, along the lake, or on the river, it is highly valuable to protect our waters. The Elco Electric Propulsion System is a highly efficient and extremely durable alternative to fossil fuel options.
* Performance may vary based on operating conditions. The figures provided above relate to travel at between 60 – 80% of hull speed.
** Shore power-50% depth of discharge
To convert from nautical miles (nm) to statute miles multiply nm by 1.15.
With Electric Hybrid system additional kilowatts should be added depending on house loads (1,000 watts equals 1kW)
| Battery Voltage | 48 |
| Amps (Maximum DC Input Current) | 135 |
| Maximum RPM | 1,500 |
| Continuous Output KW Rating | 6kW |
| Length | 13.9″ |
| Width | 12.7″ |
| Height | 11″ |
| Weight | 70lbs |
| Maximum Operating Voltage | 69Vdc |
| Minimum Operating Voltage | 40Vdc |
The Elco EP-12 Electric Inboard Motor is a battery-powered marine propulsion system designed as an eco-friendly replacement for conventional diesel or gasoline engines in the 8 to 12 horsepower (HP) range. This system is highly popular for sailboats, launches, and displacement-hull vessels ranging from 20 to 35 feet in length.
Key Technical Specifications – Electric Inboard Elco EP-12hp
Equivalent Power Capacity: 12 HP (Replaces 8–18 HP diesel/gasoline engines).
System Voltage: 48 Volts DC.
Power Consumption: Continuous output of approximately 5.1 kW to 6 kW (Peak power reaches 8.8 kW).
Rotational Speed (RPM): 1,500 RPM (Increases to 1,800 RPM in Power Boost mode).
Motor Weight: Approximately 31.8 kg (70 lbs) for the latest airflow-design model.
Physical Dimensions: Length 353 mm × Width 323 mm × Height 279 mm.
Expected Service Life: Over 50,000 hours of operation, thanks to AC induction/PMAC motor technology featuring only a single moving part.
