New Yamaha F75 75HP 4 Stroke Long Shaft Outboard Engine

New Yamaha F75 75HP 4 Stroke Long Shaft Outboard Engine

FEATURES :

Updated look: The compact new F75 adopts an updated cowling to keep it consistent with the look of the Yamaha outboard lineup.
Multi-point fuel injection: With Multi-point Fuel Injection, Fuel is delivered at the optimum volume and time according to ECU sensor signals. This ensures quick starts, efficient fuel consumption, and ample power along with ultra-low emissions.
Command link compatibility: The F75 is compatible with Yamaha’s Command Link 6Y8 and 6YC digital gauges, as well as Y-COP.

SPECS :

ENGINE

ENGINE TYPE    4-cylinder
DISPLACEMENT    1596cc (97ci)
BORE & STROKE    79×81.4mm (3.11×3.2in)
RPM RANGE    5000-6000
COMPRESSION RATIO    9.6:1
INDUCTION SYSTEM    DOHC
ALTERNATOR OUTPUT    20 Amps
FUEL DELIVERY    EFI
STARTING    Electric
IGNITION    TCI microcomputer
LUBRICATION    Wet sump
DEGREE OF TRIM/TILT    -4° through 16°/70°
EXHAUST    Through Prop
COOLING    Water/Thermostatic Control
GEAR SHIFT    F/N/R
GEAR RATIO    11:25 (2.27)

FUEL & LUBRICATION

RECOMMENDED FUEL    Regular Unleaded (Minimum Pump Octane 87)
RECOMMENDED OIL    Yamalube 4-M FC-W 10W-30 or 20W-40
OIL CAPACITY    4.5L (4.8 qt)

DIMENSIONS

SHAFT LENGTH    20″
DRY WEIGHT    168kg (369 lb)

The new Yamaha F75LB is a lightweight, 1.8-liter, 4-stroke 75HP outboard with a 20-inch (long) shaft, featuring 16-valve SOHC, EFI, and a 35-amp alternator. Designed for inshore, it offers superior power-to-weight ratio, <25>variable trolling (VTS)</25>, and <25>Command Link digital gauge compatibility</25>. It is ideal for 16-18 ft boats requiring efficient, quiet, and reliable performance.

Key Features & Specifications:

Engine Type: 4-Stroke, 16-Valve SOHC Inline 4-Cylinder
Displacement: 1.8 Liters (1832 cc)
Weight: ~162 kg (353 lbs)
Shaft Length: 20-inch (Long Shaft – F75LB)
Fuel Management: Electronic Fuel Injection (EFI)
Alternator Output: 12V – 35A
Trim and Tilt: Power Trim & Tilt
Steering: Remote Mechanical

Performance & Efficiency:

Variable Trolling Switch (VTS): Allows RPM adjustment in 50-RPM increments (550 to 1000 RPM).
Fuel Efficiency: 10% improved fuel economy compared to previous generations.
Corrosion Protection: Features YDC30 marine aluminum alloy, stainless steel components, and sacrificial anodes.

Compatibility:

Command Link: Compatible with Yamaha’s digital gauges.
NMEA 2000: Supports third-party display integration.
Installation: Uses standard mounting holes for easy installation.
