New Yamaha F30 30HP 4 Stroke Outboard Engine

New Yamaha F30 30HP 4 Stroke Outboard Engine

MIDRANGE 30 hp

Our 747-cc 30-hp midrange boasts a streamlined design and solid performance. At just 214 pounds, it’s suitable for lightweight craft such as aluminum fishing boats and inflatables. Its Nitro Assist Tilt makes tilting almost effortless.

Available for mechanical or tiller-handle control
Only 214 pounds
Available in a 20” shaft
Powerful 17-amp alternator
Optional Variable Trolling RPM Switch (VTS®) via our Multi-Function Tiller Handle, Command Link tachometer or new helm-mounted remote VTS switch.

KEY FEATURES New Yamaha F30 30HP 4 Stroke Outboard Engine

Responsive power: A single overhead camshaft provides precise valve timing for maximum power with minimum weight. This 6-valve, SOHC design efficiently exchanges intake and exhaust gases for responsive power and fuel efficiency.
Precise throttle control: All air entering the engine block of the F30 is routed through a single throttle valve to ensure the precise amount of air necessary for optimum power and fuel efficiency. The air silencer box reduces intake noise and air turbulence for smooth, quiet operation.
Fuel efficiency: Three individual compact electronic fuel injectors deliver the exact amount of fuel needed for optimum performance and economy. Controlled by the Engine Control Module via input from an array of on-engine sensors, their location just above the intake valves enhances fuel atomization, resulting in more efficient combustion.

SPECS :

Engine Type    3 cyl
Displacement    747cc
Bore x Stroke    65 x 75mm (2.56 x 2.95 in.)
Prop Shaft Horsepower    30hp at 5500rpm
Full Throttle RPM Range    5000 ~ 6000 rpm
Alternator Output at W.O.T.    17 Amp
Compression Ratio    9.4:1
Fuel Induction System    EFI
Weight †    97 kg (214 lbs) – 101kg (223 lbs)
Recommended Fuel    Octane 87
Recommended Engine Oil    Yamalube® 4M (See owner’s manual)
Recommended Fuel Filtration    Yamaha 10-Micron Fuel/Water Separating Filter (external)
C.A.R.B. Rating    2-Star
Exhaust    Through Propeller
Intake    6
Ignition    CDI Microcomputer
Spark Plug    DPR6EB-9
Alternator Output    17 Amp
Starting System    Electric
Lubrication    Wet Sump
Engine Oil Capacity    1.7L/1.5L
Recommended Cooling    Thermostatic Control
Ethanol Blend Limit    10% Maximum
Gear Ratio    2.00:1
Gear Shift    Forward, Neutral, Reverse
Shaft Length    20″
Degree of Tilt    65° – 66°
Degree of Trim    -3° through 20°
Dry Weight    97 kg (214 lbs) – 101kg (223 lbs)
Mounting Centers    N/A
Steering Angle (maximum)    40° from center, either direction
Warranty    Limited 3-year Pleasure, 3-year Government, 1-Year Commercial
