New Mercury 90HP SeaPro Command Thrust 90ELPT

New Mercury 90HP SeaPro Command Thrust 90ELPT Outboard Engine

The SeaPro mid-range outboards take working to the next level—uncommonly powerful, uniquely compact, uncompromisingly reliable, and unbelievably fuel efficient. To maximize durability, upper mounts are twice as stiff as recreational models. The compact size of these mid-range outboards lets you refit older boats with more horsepower enabling them to perform better than ever with the latest technology. They’re the engines with the toughness and durability you need to get the job done.

Ultra-compact. Ultra-efficient. Ultra-durable. A motor that works hard all day long, day after day, in the toughest conditions. For commercial fishing vessels, commercial workboats and law-enforcement boats.

Features

MERCURY SEAPRO ENGINES EXCEL IN THAILAND: Sakchai Homsub and his team are out on the water 365 days a year, bringing tourists around the islands surrounding Pattaya, Thailand. As his customers rely on him, he counts on his SeaPro engines to deliver the performance required to take them out on the water day in, day out.

HARSH CONDITIONS CAN’T DETER SEAPRO: TowBoatUS and commercial boat builders turn to Mercury Marine’s SeaPro engines because they’re engineered to deliver longer engine life while maintaining the power and performance necessary to get the job done.

THE MERCURY EDGE: ANTI-CORROSION PROTECTION: Mercury SeaPro four-stroke outboards offer superior protection against corrosion with the industry’s lowest-copper aluminum alloy. And the life of critical components is extended with more stainless steel.

SPECS : New Mercury 90HP SeaPro Command Thrust 90ELPT Outboard Engine

HP / kW
90 / 67

Engine type
8-valve single overhead cam (SOHC)
Inline 4

Displacement (L)
2.1

Full throttle RPM
5000-5500

Air induction
Performance-Tuned Scroll Intake Manifold

Fuel induction system
Computer Controlled Multi-Port Electronic Fuel Injection (EFI)

Alternator amp / Watt
35 amp / 441 watt with water-cooled voltage regulator

Recommended fuel
Unleaded Regular 87 Octane Minimum (R M/2) or 90 RON 10% Ethanol Maximum

Recommended oil
NMMA Certified FCW 25W-40 Synthetic Blend

Engine protection operator warning system
SmartCraft Engine Guardian

Compatible with SmartCraft digital technology
Yes

Starting
Smart Start Electric

Controls
Mechanical throttle & shift
Steering
Big Tiller
Dual cable mechanical
Hydraulic

Shaft length
20″ / 508 mm
25″ / 635 mm

Gearcase ratio
2.38:1

Dry weight *Lightest model available
363 lbs / 165 kg

CARB star rating
3

Bore and stroke
3.5 x 3.2″ / 90 x 81 mm

Ignition
SmartCraft ECM 70 Digital Inductive

Fuel system
Electronic Fuel Injection (EFI)

Cooling system
Water-cooled with thermostat

Gear shift
F-N-R

Gearcase options
Command Thrust
Trim system
Power Tilt
Power Trim

Exhaust system
Through prop

Shallow water trim range (degrees)
20

Color
Phantom Black

Lubrication system
Wet sump

Oil Capacity
5.5 qts / 5.2l

Maximum Trim Range
22° (-6° to 16°)

Maximum Tilt Range
70° (-6° to 64°)
